Rigid-Flex PCB
Rigid-flex PCBs are integrated circuit boards that combine the features of rigid PCBs and flexible PCBs. They are typically used to save space, simplify the assembly of wiring components, and can also be soldered to complex components. As part of the packaging design, it is also common practice to integrate them with other high-tech circuit boards such as HDI boards.
10-Layer Buried Copper Block Rigid-Flex PCB
Layers:10L(Buried copper block)
Material:FR-4 HTG+PI(M6+R-F775)
Board Thicknes:2.0mm
Copper Thicknes:35/18/18/35 um
Min.Trace/Space:3/3 mil
Surface Finsh:ENIG
Finger gold-plated 40μ
rigid-flex-pcbproducts.viewMore
14-layer high-speed rigid-flex printed circuit board
Layers:14L
Material:TU-872SLK+PI+TU-872SLK
Board Thicknes:2.8mm
Copper Thicknes:35/18/18/35 um
BGA:0.2MM
Min.Hole Size:0.15mm
Surface Finsh:ENIG
rigid-flex-pcbproducts.viewMore
12-Layer DuPont Material Buried Capacitor and Buried Resistor Flex-Rigid PCB
Layers:12L
Material:FR-4 HTG+PI(TU-883+AP8525R)
Board Thicknes:1.8 mm
Copper Thicknes:35/18/18/35 um
Min.Hole Size:0.1mm
Surface Finsh:ENIG
Control impedance
rigid-flex-pcbproducts.viewMore
10-Layer HDI Structure Rigid-Flex Board
Layers:10L
Material:FR-4 +PI（Megtron7+PI）
Board Thicknes:1.6mm
Min.Hole Size:0.05mm
Surface Finsh:ENIG
second-order HDI board
